Definition of Queue and its types with algorithms (Data structure)

                               Queue

A queue is non-premitive linear data structure . It is based on first-in-first-out (FIFO) mechanism.In queue deletion can take place at one end of the list , the front of the list. And insertion can take place at the other end of the list , rear of the list.
    Queues are often usde in programming networks , operating systems , and other situations in which many different processes must share resources such as CPU time.

* Working Process on Queue :-

• By incrementing rear pointer we can insert an element in queue.
• By incrementing front pointer we can removew element from queue.
• If queue is empty then front and rear pointer must be incremented by 1 first time.
• When rear=size- 1 then queue is full.
• When front=rear then reset front=-1 and rear=-1.
• When front=rear=-1 then the queue is empty.

Queue is different from stack in many cases. Both are  non-premitive linear data structure but the mechanisms on insertion and deletion are fully different. Where queue is based on FIFO mechanism, stack is based on LIFO mechanism.

Best example of queue is the row at the ticket counter for any shows. The person who came first take ticket first , thus follows FIFO rule.

Many operations can be possible on a queue as:-

• push (insert )
• pop (delete)
• peep etc.

* Algorithm for insertion (push operation):-


   Step 1: [ Check for ovetflow condition]
                 If  rear>= size of array  then
                 Output:-"queue is overflow" and exit.

   Step 2: [Increment rear pointer]
                rear=rear+1

   Step 3: [Insert an element]
              Q[rear]=value

   Step  4: [Set the front pointer]
               If
                front =0  then,
                front =1

    step 5:    return


* Algorithm for deletion (pop operation):-

Step 1: [check for underflow condition]
             If front =0  then,
             output:- "queue is underflow" and exit.

Step 2: [remove the element]
             value=Q[rear]

Step 3: [check for empty queue]
           If  front =rear  then,
              front=0
              rear=0
          Else
               front =front+1

Step 4:   return


* There are mainly three types of queues are possible:--

i> Circular queue.
ii> Double ended queue.
iii> Priority queue.

i> Circular Queue:-
    In a normal queue , we can insert elements untill queue becomes full. But once queue becomes full      , we cannot insert the next element . The circular is dsigned to overcome the limitations of simple        queue.
       Circular Queue is a linear data structure in which the operations are performad based on FIFO      principle and last position id connected back to the first position to make a circle.

  Suppose we have an array Q that contains n elements in which Q[1] comes after Q[n] pocket in the    array. When this technique is used then the queue is called circular queue. Thus we can say that a       queue is called circular when the last room comes just before the first  room.





* Algorithm to insert element in circular queue:-

 Step 1: [Check for overflow condition ]
              If
                front=1 and rear=n  then,
              output:-  "queue is overflow" and exit.

 Step 2: [Insert element in the queue]
            Else if
                   front=0  then,
                    front=1
                     rear=1
                    Q[rear]=value

Step 3: [check if the rear at the end of the queue]
              Else if
                     rear=n  then,
                      rear=1
                    Q[rear]=value

Step 4: [Insert the element]
             Else
                  rear=rear+1
                 Q[rear]=value

Step 5:        return


* Algorithm to delete an elment from a circular queue:-

Step 1: [Check for underflow condition]
            If
             front =0  then,
            output:- "Queue is underflow" and return.

Step 2: [remove the element]
            value=Q[front]

Step 3: [Check whether the queue is empty or not]
             If
               front =rear   then
               front =0
               rear=0

Step 4: [Check the front pointer position]
            Else if
                    front =n   then,
                    front =1
          Else
                  front =front +1

Step 5: [Return the removed element]
            return(value)




  Rest two types of queue are remaining .
 Will be publish on next post.😊
